Concrete Mixer Truck(JZC350):
Since the machine is off-bipyramidal reversal discharging mobile concrete mixer, mixing semi-rigid plastic and concrete. Stir mixing tube is transferred, a reversal expected. Each tank can be mixed with 350Lconcrete (after absorption of concrete volume), to produce 10-14 million cubic meters per hour. Applies to construction sites, roads, bridges projects and small and medium-sized concrete structures plant. Mixing fixed, it can dig the hole, the hopper be flush with the ground, feed convenience and reduce labor intensity. The machine is a novel structure, with high efficiency, mixing good quality, light weight, form aesthetic advantages, is a more advanced model.
Main technical parameters:
| Overall Size | 2766(L)×2140(W)×3000(H)mm |
| Feeding capacity | 560L |
| Discharging volume | 350L |
| Productivity | 10-14m3/h |
| Roasting speed of stirring shaft | 14r/min |
| Max.diameter of aggregates | 60mm |
| Electric motors | Mixer motor | 5.5KW |
| Lift motor | 5.5KW | |
| Pump motor | 0.55KW |
